A revolutionary new age technology that gives the users the freedom to equip and automate their home appliances.
IR Remote control is a combination of infrared transmitter and infrared receiver contains 4 lights and 2 Fan with Speed Control which can be controlled wirelessly. This makes the unit very easy to operate and integrate with existing systems. The remote control operates the corresponding function on the receiver board, i.e. Light 1, Light 2, etc. Switching contact can control any equipment in momentary mode (On till key pressed) or Latch Mode (Toggle on each key press).
The transmitter uses a modulated 40 kHz carrier to transmit data about which button is pressed. This method is used in all IR remote controls as it offers a high degree of noise immunity against interfering light sources. At the receiver end the IR receiver module extracts the data signal from the carrier.
- Transmitter operating range up to 10 Mts visible distance
- Compact 3V Battery Operated Transmitter
- Receiver Indicates output status by LED
- Receiver operates from 9V AC or DC power supply
- Custom Build Remote Control with Sleek match.
- Enables you to control your lights and fans through a remote control within 10 meter range
- Displays the current speed of fans and gives you the option to modulate it just by the touch of a button.
- Is a boon to physically disabled persons and senior citizen to be able to independently operate their home switching without having to rely on anyone else
Transmitter Parameter Value
- Operating Voltage 3.0V DC Battery
- Idle Operating Current < 0.1 mA @3.0VDC
- Active Operating Current on Key Pressed 4 mA @3.0V DC
- Infrared Carrier Frequency / Duty Cycle +/- 2% 40 kHz / 50%
- Range of Operation Approx. 10 Mts
Receiver Parameter Value
- Operating Voltage 9.0V DC Adapter
- Operating Current 15 mA @5.0VDC
- Operating Current 150.0 mA @5.0V DC
- Infrared Carrier Frequency / Duty Cycle +/- 2% 40 kHz / 50%
- Infrared Detector Frequency 40 kHz / 50%
